RIBBED STEEL DOORS

C.H.I. offers commercial overhead door solutions that provide powerful performance and rugged reliability for a wide variety of commercial, warehouse, and industrial applications. Our pan-constructed overhead doors are available in both insulated and non-insulated versions as well as in a variety of gauges so you can specify the right door for the application you need.

MODEL SELECTION CHART

ModelInsulationR-ValueSection Gauge & ThicknessMax SizeSpec Sheets
Insulated Ribbed Steel Doors
32211-1/2″ Polystyrene8.020 gauge steel exterior/vinyl back
2” Thick Section		24’2″ x 16’0″3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
32221-1/2″ Polystyrene8.020 gauge steel exterior/steel back
2” Thick Section		24’2” x 16’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
32411-1/2″ Polystyrene8.024 gauge steel exterior/vinyl back
2” Thick Section		34’2” x 20’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
32421-1/2″ Polystyrene8.024 gauge steel exterior/steel back
2” Thick Section		24’2” x 18’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
32511-1/2″ Polystyrene8.025 gauge steel exterior/vinyl back
2” Thick Section		20’2” x 16’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
32521-1/2″ Polystyrene8.025 gauge steel exterior/steel back
2” Thick Section		20’2” x 16’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
Non-Insulated Ribbed Steel Doors
3220N/AN/A20 gauge steel exterior24’2” x 16’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
3240N/AN/A24 gauge steel exterior40’2” x 20’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
3250N/AN/A25 gauge steel exterior20’2” x 16’0”3-Part Spec
Spec Data Sheet
Section Drawing
BIM Objects
Product Flyer
